HTML Puzzles

These puzzles manipulate HTML elements.

What is HTML DOM?

HTML DOM (Document Object Model, see techie stuff here) is a programmatic interface to an HTML page. Basically, this means you can modify your app not only by editing its source code, but also by executing various Puzzle blocks. For example, you can add new HTML elements, customize how the page looks, draw something on top of your models, take sceenshots, download files etc.

Puzzles Reference

add HTML element

Creates an HTML element with a specified type and identifier (corresponds to id attribute) and adds it to, right before, or right after the specified existing HTML element.

The in parent doc checkbox should be enabled if the created element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

Adding HTML elements with visual programming blocks

For example, to create a red-colored link to the Soft8Soft website, you might use the following puzzles:

remove HTML element

Removes an HTML element with a specified identifier. The in parent doc checkbox should be enabled if the removed element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

Removing HTML elements with visual coding

set property

Sets an property for an HTML element with a specified id. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe). This puzzle also works with lists of element ids.

Visual programming block to set HTML element property

Property	Description
alt	Specifies an alternate text when the original element fails to display.
checked	Specifies checked state for a checkbox/radio element.
className	Sets the value of the class attribute of an element.
download	Specifies that the target will be downloaded when a user clicks on the hyperlink.
disabled	Specifies that the specified element/group of elements should be disabled.
height	Specifies the height of the element.
href	Specifies the URL of the page the link goes to.
id	Specifies a unique id for an element.
innerHTML	Sets the HTML content of an element.
loop	Specifies that the audio/video will start over again, every time it is finished.
muted	Specifies that the audio/video should be muted.
rel	Specifies the relationship between the current document and the linked document.
scrollLeft	Sets the number of pixels an element's content is scrolled horizontally.
scrollTop	Sets the number of pixels an element's content is scrolled vertically.
src	Specifies the URL of the loaded file.
style	Specifies an inline CSS style for an element.
tabIndex	Sets the tabIndex property for an element.
target	Specifies the target for where to open the linked document or where to submit the form.
textContent	Sets the text content of an element.
title	Specifies extra information about an element.
type	Specifies the type of element.
value	Specifies the value of the element.
volume	Specifies volume for the audio/video element.
width	Specifies the width of the element.

get property

Gets an property from an HTML element with a specified id. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe)..

Visual programming block to get HTML element property

Property	Description
alt	Gets an alternate text when the original element fails to display.
checked	Gets the checked state of the checkbox/radio element.
className	Gets the value of the class attribute of an element.
download	Gets the download attribute on the element.
disabled	Gets the disabled state of the element.
height	Gets the elemnt height.
href	Gets the URL of the page the link goes to.
id	Gets a unique id for an element.
innerHTML	Gets the HTML content of an element.
loop	Gets looping state of the audio/video element.
muted	Gets muted state of the audio/video element.
rel	Gets the relationship between the current document and the linked document.
scrollLeft	Gets the number of pixels an element's content is scrolled horizontally.
scrollTop	Gets the number of pixels an element's content is scrolled vertically.
src	Gets the URL of the loaded file.
style	Gets an inline CSS style for an element.
tabIndex	Gets the tabIndex property of the element.
target	Gets the target for where to open the linked document or where to submit the form.
textContent	Gets the text content of an element (and all its children).
title	Gets extra information about an element.
type	Gets the type of element.
value	Gets the value of the element.
volume	Gets the volume of the audio/video element.
width	Gets the width of the element.

create css rule

Creates a new CSS rule. The in parent doc checkbox should be enabled if the style sheets belong to an external HTML document (i.e. when app's .html file is embedded using iframe).

set style

Sets a CSS property for an HTML element with a specified id. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe). This puzzle also works with lists of element ids.

get style

Gets a CSS property from an HTML element with a specified id. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

This puzzle can be very useful to make 3D configurators. For example, you can use the following setup to assign material color from the background color of some HTML element:

Assigning background color of HTML elements with visual scripting blocks

set css rule

Sets a CSS property for a specified CSS rule (found in .css files of an application). The in parent doc checkbox should be enabled if the style sheets belong to the parent HTML document (i.e. when app's .html file is embedded using iframe).

event

Registers an event listener for an HTML element with a specified id. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe). Once an event occurs, the puzzles placed in the do slot are triggered. Also works with lists of element ids.

get event property

Outputs the value of a property of an event generated by the "event" puzzle.

Visual scripting chunk to retrieve DOM event props

DOM object selector

Represents the canvas container element - an HTML element which contains a rendered scene, DOM window object - a browser tab or an iframe to which an HTML document is loaded, DOM document object - the root node of an HTML document, or DOM body object - the <body> element of an HTML document.

query selector

Returns the first HTML element that matches a specified CSS selector.

create canvas elem

Creates a canvas element with id, width, and height attributes. Use this puzzle with replace texture to create canvas textures.

Visual programming block to create HTML canvas

Once created, the canvas becomes available for drawing on it via JavaScript. You can update the canvas inside the runCode() function of your_app_name.js module or by using the exec script puzzle.

To update the canvas, retrieve the canvas texture by its ID (specified as id attribute):


    var canvasTex = puzzles.canvasTextures['my_canvas'];

After that, you can access the HTML canvas element as follows:


    var canvas = canvasTex.image;

You can use the standard methods available for drawing on the HTML canvas. For example, the following listing draws a blue smiling face on white background:


    var ctx = canvas.getContext("2d");

    ctx.fillStyle = 'white';
    ctx.strokeStyle = 'blue';

    ctx.fillRect(0, 0, canvas.width, canvas.height);

    ctx.beginPath();
    ctx.arc(75, 75, 50, 0, Math.PI * 2, true); // Outer circle
    ctx.moveTo(110, 75);
    ctx.arc(75, 75, 35, 0, Math.PI, false);  // Mouth (clockwise)
    ctx.moveTo(65, 65);
    ctx.arc(60, 65, 5, 0, Math.PI * 2, true);  // Left eye
    ctx.moveTo(95, 65);
    ctx.arc(90, 65, 5, 0, Math.PI * 2, true);  // Right eye
    ctx.stroke();

Finally, if you’d like the updates to become immediately visible in the 3D rendering, you should mark the canvas texture as dynamic:


    canvasTex.needsUpdate = true;

Working with HTML canvas using visual logic blocks

For usage example, check out the following demo from the Asset Store: Canvas Texture.

draw line

Connects a specified 3D object with a specified HTML element by a dynamically updated line. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe). You can also set the width, color and offset for the line.

remove line

Removes a previously created line from a specified object.

bind element

Makes a specified HTML element follow the center of a specified 3D object in screen space. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

Visual programming block to bind HTML element

Notes:

You can use the add annotation puzzle instead and customize the look of the annotations as described here.

unbind element

Unbinds the specified HTML element, previously binded to an object. The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

Visual programming block to unbind HTML element

init fullscreen

Makes a specified HTML element behave as a fullscreen mode button - the first click on it triggers entering the fullscreen mode, the second click exits fullscreen. Puzzles placed in the "on enter do" and "on exit do" slots are triggered upon entering or exiting the fullscreen mode. Puzzles placed in the "if unavailable do" are triggered if fullscreen is not supported by the browser (e.g. iOS Safari).

Entering fullscreen mode with visual logic blocks

open web page

When this puzzle is triggered, a specified URL is opened in a new or in the same browser tab depending on the drop-down selection. When triggered from the Puzzles editor, it will ask for a user confirmation before leaving the tab.

Visual programming block to open new pages

Options:

a new tab: Open URL in a new tab. To overcome the browser restriction which prevents opening new tabs, you must use this puzzle inside when clicked or event puzzle.
the same tab: Open in the same tab.
the same tab (ignore frames): Open in the same tab. Used for iframe-ed apps to open page inside the top-most browsing context.
the same tab (parent frame): Open in the same tab. Used for iframe-ed apps to open page inside the parent browsing context.
replace URL (no reload): Just put a given URL to the browser address bar.

social share link

Generates a link for sharing your application in popular social media.

Creating social media links with visual programming blocks

set URL param

Assigns or updates a value of a parameter in a specified URL by automatically forming a valid query string if necessary, and returns the updated URL.

This puzzle may be useful in situations when the configuration data of an application are stored in its URL. For example, you can specify an image to be used as a texture in the following way:


    https://www.example.com/my_awesome_app.html?image_url=https://www.uploadserver.com/path/to/image.jpg

You can upload a texture, retrieve its server-side path and save it to the image_url parameter of the app URL as follows:

Example of setting URL params with logic blocks

For usage example, check out the following demo from the Asset Store: Custom Image.

take screenshot

Takes a screenshot of the viewport and outputs it in Data URI format.

Taking screenshots with visual programming blocks

Notes:

You should also enable screenshots for your app using the configure application puzzle, otherwise black images will be produced.

get URL data

Retrieves URL data of the window to which an application is loaded:

Entire URL — text, e.g. "https://www.example.com/my_awesome_app.html?image_url=https://www.uploadserver.com/path/to/image.jpg"
Parameters — dictionary, e.g. {"image_url": "https://www.uploadserver.com/path/to/image.jpg"}
Host name — text, e.g. "www.example.com"

The in parent doc checkbox should be enabled if the HTML element is located in the parent HTML document (i.e. when app's .html file is embedded using iframe).

Getting URL data by using visual coding blocks

This puzzle may be useful in situations when the configuration data of an application are stored in its URL. For example, you can specify an image to be used as a texture in the following way:


    https://www.example.com/my_awesome_app.html?image_url=https://www.uploadserver.com/path/to/image.jpg

Then you can retrieve the image_url parameter, load and apply the texture as follows:

Example of getting URL data with visual programming block

For usage example, check out the following demo from the Asset Store: Custom Image.

download file

Downloads content specified in Data URI format to a file. You can also pass text, dictionary, or list data to be downloaded as text or JSON file. In such case, the given object will be automatically converted to the appropriate Data URI.

This puzzle can be used, for example:

to save previously taken screenshots
to preserve application state by saving a dictionary (or a list) to a *.json file
to export models in glTF format for further processing
to generate textual pricing information, quotes, reports etc.

open file

Invokes the browser's native dialog window for selecting files from the user's device. Once the user have selected a file, returns the file's contents/info by means of the opened file puzzle.

opened file

Returns file contents or metadata.

Options:

data

File contents encoded in Data URI format.

name

File name.

extension

File extension without leading dot: txt, jpg, mp3, etc...

size

File size in bytes.

mime type

File media type (aka MIME type). List of mime types typically used by Verge3D applications include:

application/json	JSON file, can also be used for glTF assets.
application/octet-stream	Binary (.bin) file.
audio/mpeg	MP3 file.
image/jpeg	JPEG image.
image/png	PNG image.
text/csv	A file with comma-separated values (CSV).
text/plain	Plain text file (TXT).
video/mp4	MPEG-4 video.

drop file to

Returns a file dragged from a file manager (or other program) and dropped to the given HTML element inside the browser window. Once the user have dropped the file, returns its contents/info by means of the opened file puzzle.

Visual programming block for dropping files to HTML page

You can activate the optional drag over slot to handle file movement events. For example, you can use it along with the raycast puzzle to highlight the objects below the cursor/touch.

How to specify URL paths to web resources

For some puzzles one should specify the URL (aka URI) paths to some web resource, e.g:

open web page — web page to go.
replace texture — path to the texture.
load sound — path to the sound asset.
load scene — glTF asset.
create text object — font.

When talking about URL paths, you need to understand that these are completely different from the paths you see on your local machine because all resources on the web are accessed indirectly, by means of web browsers that fetch resources from web servers.

Basically that means you never specify URL paths like these:

C:\Users\User\Documents\verge3d_apps\my_app\my_scene.gltf
/Users/User/Downloads/my_sound.mp3
/home/user/Desktop/my_texture.jpg

Paths on the web specified only with forward slashes (/) and can be:

Relative

These paths specified relatively to the app HTML:

my_scene.gltf or ./my_scene.gltf — the scene located in the same directory as the app HTML file.
sounds/my_sound.mp3 — the sound located in the sounds subdirectory of the directory where app HTML stored.
../textures/my_texture.jpg — the texture located in the textures directory which is located one level up (thats why two dots for) from the directory of the app HTML file.

Absolute

These used to specify paths when you know where exactly the resource is located on the web server:

https://www.my_host.com/my_app/my_scene.gltf — the scene stored in the my_app directory on the my_host server.
/my_app/fonts/my_font.woff — the font stored in the fonts subdirectory of the my_app directory on whatever (its name is not known or does not matter) host.

Data URI

Special kind of URL which represents encoded resource which is not stored on a web server. We use such links to return data generated or retrieved by some puzzles. Read more about them here.

Data URI Links

Data URI (aka Data URL) is a convenient method to embed various assets, such as images, glTF models, sounds, JSON or CSV inside links (techie stuff).

For example, the following link represents small Verge3D logo:

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Copy the entire snippet and past to the browser address bar to display the logo:

In Puzzles, we use Data URI links extensively, as they provide convenient way to pass file-like data between different Puzzles blocks. For example, you can use the open file or drop file to puzzles to load some file (image or data). Then you can make changes in your scene according to that file. After that, you can upload the modified scene (or maybe some data, such as price list document) back to the user machine by using the download file, or maybe upload that file to the server with send data puzzle. In all these cases, the data will be transferred using the Data URI format.

For usage example, check out the following demo from the Asset Store: Custom Image.

It's also quite easy to debug data in Data URI format. Simply use the print to console puzzle, then open the browser console to observe the output, then click on the printed URI inside the console to preview the data in the separate browser tab.

Having Troubles with Puzzles?

Seek help on the forums!

HTML Puzzles

Contents

What is HTML DOM?

Puzzles Reference

add HTML element

remove HTML element

set property

get property

create css rule

set style

get style

set css rule

event

get event property

DOM object selector

query selector

create canvas elem

draw line

remove line

bind element

unbind element

init fullscreen

open web page

social share link

set URL param

take screenshot

get URL data

download file

open file

opened file

drop file to

How to specify URL paths to web resources

Data URI Links

Having Troubles with Puzzles?
